Managed Switch CLI Manual, Release 8.0.3
Utility Commands 9-13
v1.0, July 2010
If you enter the interface <unit/slot/port> parameter, in addition to the MAC
Address and Status fields, the following field appears:
The following information displays if you enter the count parameter:
show process cpu
This command provides the percentage utilization of the CPU by different tasks.
Status The status of this entry. The meanings of the values are:
• Static—The value of the corresponding instance was added by the system or a user
when a static MAC filter was defined. It cannot be relearned.
• Learned—The value of the corresponding instance was learned by observing the source
MAC addresses of incoming traffic, and is currently in use.
• Management—The value of the corresponding instance (system MAC address) is also
the value of an existing instance of dot1dStaticAddress. It is identified with interface 0/
1. and is currently used when enabling VLANs for routing.
• Self—The value of the corresponding instance is the address of one of the switch’s
physical interfaces (the system’s own MAC address).
• GMRP Learned—The value of the corresponding was learned via GMRP and applies to
Multicast.
• Other—The value of the corresponding instance does not fall into one of the other
categories.
Term Definition
VLAN ID The VLAN on which the MAC address was learned.
Term Definition
Dynamic
Address count
Number of MAC addresses in the forwarding database that were automatically learned.
Static Address
(User-defined)
count
Number of MAC addresses in the forwarding database that were manually entered by a
user.
Total MAC
Addresses in
use
Number of MAC addresses currently in the forwarding database.
Total MAC
Addresses
available
Number of MAC addresses the forwarding database can handle.
Term Definition
