10.2.8 Supervision of task operation (RUN error)
Task operations in the IED are monitored every two minutes. Error messages can be screened
when the tasks stop. The tasks are supervised every 15 minutes if they are idling.
(i) Error level
The error level has been set at level 1 (Serious error) unconditionally.
(ii) Error message
When detecting an error, the error message can be shown on the LCD and the LED is lit.
Table 10.2-17 Error messages provided by the supervisor in MNT_LOGIC
Message and level
Meaning of the information
CP1M(RUN) error
Detection of the stopped task in the IED
Error level
Serious error (Level 1)
Table 10.2-18 Detailed information in Hexadecimal in MNT_LOGIC
Display
area
Meaning of the detailed information
Left column
Right column
Top
row
10000000: Supervision function itself
20000000: Idle task (1)
40000000: Idle task (2)
WW XX YY ZZ
WW: FB index in SSP2(2)
XX: FB index in SSP2(1)
YY: FB index in SSP1(2)
YY: FB index in SSP1(1)
Middle
row
WW XX YY ZZ
WW: FB index in PCM(2)
XX: FB index in PCM(1)
YY: FB index in SSP3(2)
YY: FB index in SSP3(1)
WW XX YY ZZ
WW: FB index in 100MS(2)
XX: FB index in 100MS(1)
YY: FB index in 10MS
YY: FB index in 5MS
Bottom
row
WW XX YY ZZ
WW: FB index in CONVSET
XX: FB index in NMT
YY: FB index in 200MS(2)
YY: FB index in 200MS(1)
WW XX YY ZZ
WW: FB index in SUB4
XX: FB index in SUB3
YY: FB index in SUB2
YY: FB index in SUB1
