2.17.8 Data ID
◆ Signal monitoring point
OCN(Function ID: 443001)
Element ID
Name
Description
OCN-ARC-BLOCK
8500001B62
Autoreclose block signal by OCN protection
OCN-OPT-ALARM
8400001B61
Alarm signal by OCN protection
OCN-OPT-TRIP
8300001B23
Trip signal by OCN protection
OCN1
8000011C23
OCN1 relay element operated
OCN1-ARC-BLOCK
8200011B62
Autoreclose block signal by OCN1 protection
OCN1-OPT
8000011B60
OCN1 protection operated
OCN1-OPT-ALARM
8100011B61
Alarm signal by OCN1 protection
OCN1-OPT-TRIP
8000011B23
Trip signal by OCN1 protection
OCN1PU
8000011C27
OCN1 relay operation level pick up
OCN1_BLOCK
8000011BB0
OCN1 protection block command
OCN1_INST_OP
8000011BB1
OCN1 protection instant operation command
OCN2
8100021C23
OCN2 relay element operated
OCN2-ARC-BLOCK
8200021B62
Autoreclose block signal by OCN2 protection
OCN2-OPT
8100021B60
OCN2 protection operated
OCN2-OPT-ALARM
8100021B61
Alarm signal by OCN2 protection
OCN2-OPT-TRIP
8000021B23
Trip signal by OCN2 protection
OCN2PU
8100021C27
OCN2 relay operation level pick up
OCN2_BLOCK
8100021BB0
OCN2 protection block command
OCN2_INST_OP
8100021BB1
OCN2 protection instant operation command
OCN3
8200031C23
OCN3 relay element operated
OCN3-ARC-BLOCK
8200031B62
Autoreclose block signal by OCN3 protection
OCN3-OPT
8200031B60
OCN3 protection operated
OCN3-OPT-ALARM
8100031B61
Alarm signal by OCN3 protection
OCN3-OPT-TRIP
8000031B23
Trip signal by OCN3 protection
OCN3PU
8200031C27
OCN3 relay operation level pick up
OCN3_BLOCK
8200031BB0
OCN3 protection block command
OCN3_INST_OP
8200031BB1
OCN3 protection instant operation command
OCN4
8300041C23
OCN4 relay element operated
OCN4-ARC-BLOCK
8200041B62
Autoreclose block signal by OCN4 protection
OCN4-OPT
8300041B60
OCN4 protection operated
OCN4-OPT-ALARM
8100041B61
Alarm signal by OCN4 protection
OCN4-OPT-TRIP
8000041B23
Trip signal by OCN4 protection
OCN4PU
8300041C27
OCN4 relay operation level pick up
OCN4_BLOCK
8300041BB0
OCN4 protection block command
OCN4_INST_OP
8300041BB1
OCN4 protection instant operation command
◆ Connection point on PLC logic
OCN(Function ID: 443001)
Element ID
Name
Description
800001EBB0
OCN1_BLOCK
OCN1 protection block command
800001EBB1
OCN1_INST_OP
OCN1 protection instant operation command
810002EBB0
OCN2_BLOCK
OCN2 protection block command
810002EBB1
OCN2_INST_OP
OCN2 protection instant operation command
