2.27.4 Data ID
◆ Signal monitoring point
OSTV(Function ID: 479001)
Element ID
Name
Description
8000001B60
OSTV
OSTV protection operated
8000001BB0
OSTV BLOCK
OSTV detect block
8000011C23
OSTV-1
OSTV-1 relay element operated
8100021C23
OSTV-2
OSTV-2 relay element operated
8200031C23
OSTV-3
OSTV-3 relay element operated
8300041C23
OSTV-4
OSTV-4 relay element operated
8200001B61
OSTV-OPT
OSTV protection block command
8300001B23
OSTV-OPT-TRIP
OSTV-OPT-TRIP scheme operated
◆ Connection point on PLC logic
OSTV(Function ID: 479001)
Element ID
Name
Description
800000EBB0
OSTV BLOCK
OSTV detect block
