(iii) Measurand in Soft 33 and VCT11B operating with 2 remote terminals
Measurand Data IDs
Measurand to be used in
Software 33(VCT11B)
Metering
values
Types of inputs
Unit
GR-TIEMS and
IEC103
IEC61850
Fault recording
Note
IaB
IaB measurement primary
A
7110014301001076
7110014201601076
7110014301301076
IaB-Angle
IaB-Angle measurement angle
deg
7110014301001051
7110014201601051
7110014301301051
IbB
IbB measurement primary
A
7110014301001078
7110014201601078
7110014301301078
IbB-Angle
IbB-Angle measurement angle
deg
7110014301001053
7110014201601053
7110014301301053
IcB
IcB measurement primary
A
711001430100107A
711001420160107A
711001430130107A
IcB-Angle
IcB-Angle measurement angle
deg
7110014301001055
7110014201601055
7110014301301055
IcaB
IcaB measurement primary
A
711001430101107A
711001420161107A
711001430131107A
IcaB-Angle
IcaB-Angle measurement angle
deg
7110014301011055
7110014201611055
7110014301311055
IbcB
IbcB measurement primary
A
7110014301011078
7110014201611078
7110014301311078
IbcB-Angle
IbcB-Angle measurement angle
deg
7110014301011053
7110014201611053
7110014301311053
IabB
IabB measurement primary
A
7110014301011076
7110014201611076
7110014301311076
IabB-Angle
IabB-Angle measurement angle
deg
7110014301011051
7110014201611051
7110014301311051
IeB
IeB measurement primary
A
71100143010A107C
71100142018D107C
711001430137107C
IeB-Angle
IeB-Angle measurement angle
deg
71100143010A1057
71100142018D1057
7110014301371057
I1B
I1B measurement primary
A
7110014301021076
7110014201621076
7110014301321076
I1B-Angle
I1B-Angle measurement angle
deg
7110014301021051
7110014201621051
7110014301321051
I2B
I2B measurement primary
A
7110014301021078
7110014201621078
7110014301321078
I2B-Angle
I2B-Angle measurement angle
deg
7110014301021053
7110014201621053
7110014301321053
I0B
I0B measurement primary
A
711001430102107C
711001420162107C
711001430132107C
I0B-Angle
I0B-Angle measurement angle
deg
7110014301021057
7110014201621057
7110014301321057
Iem
Iem measurement primary
A
711001430103107C
711001420163107C
711001430133107C
Iem-Angle
Iem measurement angle
deg
7110014301031057
7110014201631057
7110014301331057
Va
Va measurement primary
V
7110014302041076
7110014202641076
7110014302341076
Va-Angle
Va measurement angle
deg
7110014302041051
7110014202641051
7110014302341051
Vb
Vb measurement primary
V
7110014302041078
7110014202641078
7110014302341078
Vb-Angle
Vb measurement angle
deg
7110014302041053
7110014202641053
7110014302341053
Vc
Vc measurement primary
V
711001430204107A
711001420264107A
711001430234107A
Vc-Angle
Vc measurement angle
deg
7110014302041055
7110014202641055
7110014302341055
Vca
Vca measurement primary
V
711001430205107A
711001420265107A
711001430235107A
Vca-Angle
Vca measurement angle
deg
7110014302051055
7110014202651055
7110014302351055
Vbc
Vbc measurement primary
V
7110014302051078
7110014202651078
7110014302351078
Vbc-Angle
Vbc measurement angle
deg
7110014302051053
7110014202651053
7110014302351053
Vab
Vab measurement primary
V
7110014302051076
7110014202651076
7110014302351076
Vab-Angle
Vab measurement angle
deg
7110014302051051
7110014202651051
7110014302351051
V1
V1 measurement primary
V
7110014302061076
7110014202661076
7110014302361076
V1-Angle
V1 measurement angle
deg
7110014302061051
7110014202661051
7110014302361051
V2
V2 measurement primary
V
7110014302061078
7110014202661078
7110014302361078
V2-Angle
V2 measurement angle
deg
7110014302061053
7110014202661053
7110014302361053
V0
V0 measurement primary
V
711001430206107C
711001420266107C
711001430236107C
V0-Angle
V0 measurement angle
deg
7110014302061057
7110014202661057
7110014302361057
Vs
Vs measurement primary
V
711001430208107C
711001420267107C
711001430239107C
Vs-Angle
Vs measurement angle
deg
7110014302081057
7110014202671057
7110014302391057
Vs2
Vs2 measurement primary
V
711001430209107C
711001420268107C
71100143023A107C
Vs2-Angle
Vs2 measurement angle
deg
7110014302091057
7110014202681057
71100143023A1057
IaB
IaB measurement secondary
A
7110014301001050
N/A
7110014301301050
IabB
IabB measurement secondary
A
7110014301011050
N/A
7110014301311050
IbB
IbB measurement secondary
A
7110014301001052
N/A
7110014301301052
IbcB
IbcB measurement secondary
A
7110014301011052
N/A
7110014301311052
IcB
IcB measurement secondary
A
7110014301001054
N/A
7110014301301054
IcaB
IcaB measurement secondary
A
7110014301011054
N/A
7110014301311054
IeB
IeB measurement secondary
A
71100143010A1056
N/A
7110014301371056
I1B
I1B measurement secondary
A
7110014301021050
N/A
7110014301321050
I2B
I2B measurement secondary
A
7110014301021052
N/A
7110014301321052
I0B
I0B measurement secondary
A
7110014301021056
N/A
7110014301321056
Iem
Iem measurement secondary
A
7110014301031056
N/A
7110014301331056
Va
Va measurement secondary
V
7110014302041050
N/A
7110014302341050
Vb
Vb measurement secondary
V
7110014302041052
N/A
7110014302341052
Vc
Vc measurement secondary
V
7110014302041054
N/A
7110014302341054
Vab
Vab measurement secondary
V
7110014302051050
N/A
7110014302351050
Vbc
Vbc measurement secondary
V
7110014302051052
N/A
7110014302351052
Vca
Vca measurement secondary
V
7110014302051054
N/A
7110014302351054
V1
V1 measurement secondary
V
7110014302061050
N/A
7110014302361050
V2
V2 measurement secondary
V
7110014302061052
N/A
7110014302361052
V0
V0 measurement secondary
V
7110014302061056
N/A
7110014302361056
Vs
Vs measurement secondary
V
7110014302081056
N/A
7110014302391056
Vs2
Vs2 measurement secondary
V
7110014302091056
N/A
71100143023A1056
Ia-L
Ia local measurement primary
A
7110014301191076
N/A
7110014301401076
Ia-L-Angle
Ia local measurement angle
deg
7110014301191051
N/A
7110014301401051
Ib-L
Ib local measurement primary
A
7110014301191078
N/A
7110014301401078
Ib-L-Angle
Ib local measurement angle
deg
7110014301191053
N/A
7110014301401053
Ic-L
Ic local measurement primary
A
711001430119107A
N/A
711001430140107A
Ic-L-Angle
Ic local measurement angle
deg
7110014301191055
N/A
7110014301401055
Ie-L
Ie local measurement primary
A
71100143011A107C
N/A
711001430141107C
Ie-L-Angle
Ie local measurement angle
deg
71100143011A1057
N/A
7110014301411057
V1-L
V1 local measurement primary
V
711001430229107C
N/A
711001430250107C
V1-L-Angle
V1 local measurement angle
deg
7110014302291057
N/A
7110014302501057
V1-R1
V1 remote CH1 measurement primary
V
71100143022A107C
N/A
711001430251107C
V1-R1-Angle
V1 remote CH1 measurement angle
deg
71100143022A1057
N/A
7110014302511057
V1-R2
V1 remote CH2 measurement primary
V
71100143022B107C
N/A
711001430252107C
V1-R2-Angle
V1 remote CH2 measurement angle
deg
71100143022B1057
N/A
7110014302521057
Ia-R1
Ia remote CH1 measurement primary
A
71100143011D1076
71100142016D1076
7110014301441076
Ia-R1-Angle
Ia remote CH1 measurement angle
deg
71100143011D1051
71100142016D1051
7110014301441051
Ib-R1
Ib remote CH1 measurement primary
A
71100143011D1078
71100142016D1078
7110014301441078
Ib-R1-Angle
Ib remote CH1 measurement angle
deg
71100143011D1053
71100142016D1053
7110014301441053
Ic-R1
Ic remote CH1 measurement primary
A
71100143011D107A
71100142016D107A
711001430144107A
Ic-R1-Angle
Ic remote CH1 measurement angle
deg
71100143011D1055
71100142016D1055
7110014301441055
Ie-R1
Ie remote CH1 measurement primary
A
71100143011E107C
71100142016E107C
711001430145107C
Ie-R1-Angle
Ie remote CH1 measurement angle
deg
71100143011E1057
71100142016E1057
7110014301451057
Ie-R2
Ie remote CH2 measurement primary
A
711001430122107C
711001420172107C
711001430149107C
Ie-R2-Angle
Ie remote CH2 measurement angle
deg
7110014301221057
7110014201721057
7110014301491057
Ic-R2
Ic remote CH2 measurement primary
A
711001430121107A
711001420171107A
711001430148107A
Ic-R2-Angle
Ic remote CH2 measurement angle
deg
7110014301211055
7110014201711055
7110014301481055
Ib-R2
Ib remote CH2 measurement primary
A
7110014301211078
7110014201711078
7110014301481078
Ib-R2-Angle
Ib remote CH2 measurement angle
deg
7110014301211053
7110014201711053
7110014301481053
Ia-R2
Ia remote CH2 measurement primary
A
7110014301211076
7110014201711076
7110014301481076
Ia-R2-Angle
Ia remote CH2 measurement angle
deg
7110014301211051
7110014201711051
7110014301481051
Wh+
Wh+ measurement primary tool monitoring
Wh
7100014307A010A8
7110014317601098
N/A
Wh-
Wh- measurement primary tool monitoring
Wh
7100014307A110A8
7110014317611098
N/A
varh+
varh+ measurement primary tool monitoring
varh
7100014308A210A8
7110014318621098
N/A
