10.2.37 Supervision of GOOSE publishing (LAN(GOOSE)error)
Publishing error in the IEC 61850 communication† is detected when a GOOSE message is not
received.
†Note: For more information about GOOSE, see Chapter Communication protocol: IEC
61850 communication .
(i) Error level
Generally, the default error level has been set at level 3 (Minor error), but the user can program
the level using setting [CHK_GOOSERCV:LVl]; then, set On for the setting
[CHK_GOOSERCV:Sw]. Detecting the error is expressed in five-minutes when the IED detects
no reception of the GOOSE. When the GOOSE is started to receive, it is reset in one-minute.
(ii) Error message
When detecting errors, an error message can be shown on the LCD screen and an LED is lit.
Table 10.2-76 Error messages provided by the supervisor in CHK_GOOSERCV
Message and level
Meaning of the information
LAN(GOOSE) error
Detection of the failure in GOOSE
Error level
Minor error (Level 3)
Table 10.2-77 Detailed information in Hexadecimal in CHK_GOOSERCV
Display
area
Meaning of the detailed information
Left column
Right column
Top
row
Receipt state regarding to the GOOSE
subscribe information#1†
Receipt state regarding to the GOOSE
subscribe information#2†
Middle
row
Receipt state regarding to the GOOSE
subscribe information#3†
Receipt state regarding to the GOOSE
subscribe information#4†
Bottom
row
Receipt state regarding to the GOOSE
subscribe information#5†
Receipt state regarding to the GOOSE
subscribe information#6†
†Note: “c000” is shown when no reception.
