Toshiba GR200 Series - (v) Setting names

6F2S1914 (0.49)
GRL200 (Soft 033 & 037)
- 722 -
Table 4.2-36 PLC monitoring points (Output of operate signal in DPSY)
Signal Number
Signal Name
Description
511001 8202011DD3
DPSY01_OEX_BO
DPSY01 operate (CLOSE) command for Binary Output.
511001 8202021DD3
DPSY02_OEX_BO
DPSY02 operate (CLOSE) command for Binary Output.
511001 8102011DD0
DPSY01_FEX_BO
DPSY01 operate (OPEN) command for Binary Output.
511001 8102021DD0
DPSY02_FEX_BO
DPSY2 operate (OPEN) command for Binary Output.
(v) Setting names
Table 4.2-37 Setting for Binary input signals in DPSY
Setting Name
Description
Default
Setting item or value
DPSY01-CTREN
Activate control function (DPSY01)
On
Off / On
DPSY01-CTRAHMI
Activate local panel control(DPSY01)
SBO
DIR / SBO
DPSY01-EN
Activate monitoring function (DPSY01)
Close
Open / Close
DPSY01-DEVTYPE
Phase selector switch
3-pole
3-pole/1-pile/ switch
DPSY01-OPC
Activate monitoring function (DPSY01)
Close
Open / Close
DPSY01-CPC
Activate monitoring function (DPSY01)
Close
Open / Close
DPSY01A-NOPSG
BI position for DPSY01
*none
BI signal
DPSY01A-NCLSG
BI position for DPSY01
*none
BI signal
DPSY01B-NOPSG
BI position for DPSY01
*none
BI signal
DPSY01B-NCLSG
BI position for DPSY01
*none
BI signal
DPSY01C-NOPSG
BI position for DPSY01
*none
BI signal
DPSY01C-NCLSG
BI position for DPSY01
*none
BI signal
DPSY01-SPPEN
Activate event suppression for DPSY01
On
On / Off (Close/Open)
DPSY02-CTREN
Activate control function (DPSY02)
On
Off / On
DPSY02-CTRAHMI
Activate local panel control(DPSY02)
SBO
DIR / SBO
DPSY02-EN
Activate monitoring function (DPSY02)
Close
Open / Close
DPSY02-DEVTYPE
Phase selector switch
3-pole
3-pole/1-pile/ switch
DPSY02-OPC
Activate monitoring function (DPSY02)
Close
Open / Close
DPSY02-CPC
Activate monitoring function (DPSY02)
Close
Open / Close
DPSY02A-NOPSG
BI position for DPSY02
*none
BI signal
DPSY02A-NCLSG
BI position for DPSY02
*none
BI signal
DPSY02B-NOPSG
BI position for DPSY02
*none
BI signal
DPSY02B-NCLSG
BI position for DPSY02
*none
BI signal
DPSY02C-NOPSG
BI position for DPSY02
*none
BI signal
DPSY02C-NCLSG
BI position for DPSY02
*none
BI signal
DPSY02-SPPEN
Activate event suppression for DPSY02
On
On / Off (Close/Open)
DPSY-NELD
Number of change to lock status.
10
0~99
DPSY-TELD
Time to locking state( sliding window )
10[sec]
1~99[sec]
DPSY-TELR
Time to unlocking state( sliding window )
10[sec]
1~99[sec]
Table 4.2-38 Settings for health check function in DPSY
Setting Name
Description
Default
Setting item or value
DPSY01-OSLBORD
Select BO signal (BO*-RB) from signal list
*User-preferred
BO read-back signal
DPSY01-FSLBORD
Select BO signal (BO*-RB) from signal list
*User-preferred
BO read-back signal
DPSY01-OEXBORD
Select BO signal (BO*-RB) from signal list
*User-preferred
BO read-back signal
DPSY01-FEXBORD
Select BO signal (BO*-RB) from signal list
*User-preferred
BO read-back signal
DPSY02-OSLBORD
Select BO signal (BO*-RB) from signal list
*User-preferred
BO read-back signal
DPSY02-FSLBORD
Select BO signal (BO*-RB) from signal list
*User-preferred
BO read-back signal
DPSY02-OEXBORD
Select BO signal (BO*-RB) from signal list
*User-preferred
BO read-back signal
DPSY02-FEXBORD
Select BO signal (BO*-RB) from signal list
*User-preferred
BO read-back signal
