(ii) Event Record
The “Event Record” sub-menu provides three parts namely, “Event Record1”, “Event Record2”
and “Event Record3”. In each Event Record sub-menu, the data and time, device name, and
the operation of the device are displayed as shown in the example below.
Figure 12.3-6 Display of Event Record
Display of Event Record
Figure 12.3-7 shows the steps to display and erase event records. To clear all records, refer to
section (i)-3.
Figure 12.3-7 Display events
1). Move cursor to Event Record 1, 2, or 3 sub menu and press ►.
2). Event Record screen is displayed. Press ► at the Record List sub
menu.
3). Press ▲ or ▼ to move display items.
Event record1
10:48 1/3
#
1 2012-07-25
10:48:21.223
Set.Group change
2
#2 2012-07-25
10:20:21.021
Record
10:48 2/6
Fault Record >
_Event Record 1 >
Event Record 2 >
Event Record 3 >
Disturbance Record >
Clear all Records +
Event Record1
10:48 1/2
_Record List >
Clear Records +
Event Record1
10:48 1/3
#1 2012-07-25
10:48:21.223
Set. Group change
2
#
2 2012-07-25
10:20:11.021
