Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010 L 1003
8400 HighLine | Parameter setting & configuration
Function library
Function blocks | L_NSet_1
14.1.98.2 JOG setpoints
In addition to the direct main setpoint selection via the input nNSet_a, so-called JOG
setpoints can be set under C00039/1...15
.
The JOG setpoints are binary-coded and can be called using the bJog1 ... bJog8 selection
inputs so that 15 options are available:
The number of selection inputs to be assigned depends on the number of JOG setpoints
required:
14.1.98.3 Setpoint inversion
The output signal of the JOG function is led via an inverter.
The sign of the setpoint changes if bNSetInv is set to TRUE.
14.1.98.4 Value range of the input signal
The value range of the input signal can be limited by using the following parameters:
C00635
: MaxLimit (default setting: +199.99 %)
C00636
: MinLimit (default setting: -199.99 %)
Selection inputs Main setpoint
Main setpoint
bJog8 bJog4 bJog2 bJog1
FALSE FALSE FALSE FALSE nNset_a
FALSE FALSE FALSE TRUE C00039/1
FALSE FALSE TRUE FALSE C00039/2
FALSE FALSE TRUE TRUE C00039/3
FALSE TRUE FALSE FALSE C00039/4
FALSE TRUE FALSE TRUE C00039/5
FALSE TRUE TRUE FALSE C00039/6
FALSE TRUE TRUE TRUE C00039/7
TRUE FALSE FALSE FALSE C00039/8
TRUE FALSE FALSE TRUE C00039/9
TRUE FALSE TRUE FALSE C00039/10
TRUE FALSE TRUE TRUE C00039/11
TRUE TRUE FALSE FALSE C00039/12
TRUE TRUE FALSE TRUE C00039/13
TRUE TRUE TRUE FALSE C00039/14
TRUE TRUE TRUE TRUE C00039/15
Number of JOG setpoints required Number of selection inputs to be assigned (bJog1 ... bJog8)
1At least 1
2 ... 3 at least 2
4 ... 7 at least 3
8 ... 15 4
