8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00682
690 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
C00682
C00685
C00686
C00687
C00690
Parameter | Name:
C00682 | L_Compare_1: Window
Data type: INTEGER_16
Index: 23893
d
= 5D55
h
FB L_Compare_1: Window for the comparison function selected in C00680
Setting range (min. value | unit | max. value) Lenze setting
0.00 % 100.00 2.00 %
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00685 | L_Compare_2: Function
Data type: UNSIGNED_8
Index: 23890
d
= 5D52
h
FB L_Compare_2: Comparison function
• If the statement of the selected comparison operation is true, the binary output bOut is set to TRUE.
Selection list (Lenze setting printed in bold)
1In1 = In2
2In1 > In2
3In1 < In2
4 |In1| = |In2|
5 |In1| > |In2|
6 |In1| < |In2|
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00686 | L_Compare_2: Hysteresis
Data type: INTEGER_16
Index: 23889
d
= 5D51
h
FB L_Compare_2: Hysteresis for the comparison function selected in C00685
Setting range (min. value | unit | max. value) Lenze setting
0.00 % 100.00 0.50 %
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00687 | L_Compare_2: Window
Data type: INTEGER_16
Index: 23888
d
= 5D50
h
FB L_Compare_2: Window for the comparison function selected in C00685
Setting range (min. value | unit | max. value) Lenze setting
0.00 % 100.00 2.00 %
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00690 | L_Compare_3: Fct.
Data type: UNSIGNED_8
Index: 23885
d
= 5D4D
h
FB L_Compare_3: Comparison function
• If the statement of the selected comparison operation is true, the binary output bOut is set to TRUE.
Selection list (Lenze setting printed in bold)
1In1 = In2
2In1 > In2
3In1 < In2
4 |In1| = |In2|
5 |In1| > |In2|
6 |In1| < |In2|
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
