Lenze E84AVHC Series User Manual

Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010 L 689
8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00678
C00678
C00679
C00680
C00681
Parameter | Name:
C00678 | L_GainOffsetPhiP 1-2: Parameter
Data type: INTEGER_32
Index: 23897
d
= 5D59
h
Gain and offset
Setting range (min. value | unit | max. value)
-2147483647 2147483647
Subcodes Lenze setting Info
C00678/1 65536 L_GainOffsetPhiP_1
: Gain
C00678/2 0 L_GainOffsetPhiP_1
: Offset
C00678/3 65536 L_GainOffsetPhiP_2
: Gain
C00678/4 0 L_GainOffsetPhiP_2
: Offset
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00679 | L_MulDiv_2: Parameter
Data type: INTEGER_16
Index: 23896
d
= 5D58
h
FB L_MulDiv_2: Numerator and denominator
Setting range (min. value | unit | max. value)
-32767 32767
Subcodes Lenze setting Info
C00679/1 0 L_MulDiv_2
: Numerator
C00679/2 10000 L_MulDiv_2
: Denominator
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00680 | L_Compare_1: Function
Data type: UNSIGNED_8
Index: 23895
d
= 5D57
h
FB L_Compare_1: Comparison function
• If the statement of the selected comparison operation is true, the binary output bOut is set to TRUE.
Selection list (Lenze setting printed in bold)
1In1 = In2
2In1 > In2
3In1 < In2
4 |In1| = |In2|
5 |In1| > |In2|
6 |In1| < |In2|
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00681 | L_Compare_1: Hysteresis
Data type: INTEGER_16
Index: 23894
d
= 5D56
h
FB L_Compare_1: Hysteresis for the comparison function selected in C00680
Setting range (min. value | unit | max. value) Lenze setting
0.00 % 100.00 0.50 %
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
