8400 HighLine | Parameter setting & configuration
Working with the FB Editor
Printing the interconnection
866 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
13.6 Printing the interconnection
The interconnection can be printed for documentation purposes, optionally on one page,
on four pages, or not scaled.
Tip!
By clicking the icon in the FB Editor toolbar, you can get a print view before
printing.
How to print the interconnection:
1. In the FB Editor toolbar, click the icon.
•The Circuit print size dialog box is displayed.
2. Select the desired size and press OK.
• The standard dialog box Print appears.
3. Press OK to start the printing process.
