Lenze E84AVHC Series User Manual

Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010 L 483
8400 HighLine | Parameter setting & configuration
Diagnostics & error management
Error messages of the operating system
OC13: Maximum current for Fch exceeded [xx.0123.00090]
OT2: Speed controller output limited [xx.0123.00093]
FCH1: Switching frequency reduction [xx.0123.00094]
FCH2: Maximum speed for Fchop [xx.0123.00095]
OC14: Direct-axis current controller limitation [xx.0123.00096]
Response (Lenze setting printed in bold)
 None : Fault  Trouble  TroubleQuickstop  Warning  WarningLocked  Information
Cause Remedy
The device has detected a motor current which exceeds
the maximum current limit at permanent switching
frequency of the inverter.
• If a permanent switching frequency inverter is set, a
certain limit arises for the maximum current,
depending on the setting. If this current limit is
exceeded due to a load impulse or overload, an error
message is displayed.
• Observe the maximum current setting depending on
the set switching frequency of the inverter.
• Reduce the required load or setting of the dynamic
switching frequency if necessary.
Response (Lenze setting printed in bold) Setting: C00567 (; Adjustable response)
: None ; Fault  Trouble  TroubleQuickstop ; Warning  WarningLocked  Information
Cause Remedy
The output of the speed controller has reached the
internal limit value. In this state, the speed controller is
not able to correct the system deviation anymore.
• Only in "VFCplus: V/f linear/quadratic + encoder" or
SLVC (vector control) operation.
• Observe load requirements.
• Correct dimensioning or reduce setpoint generation
dynamics if necessary.
Motor control
Response (Lenze setting printed in bold) Setting: C00590 (; Adjustable response)
: None ; Fault  Trouble  TroubleQuickstop ; Warning  WarningLocked  Information
Cause Remedy
Load-dependent switching frequency reduction • Observe load requirements.
• Correct dimensioning or reduce setpoint generation
dynamics if necessary.
Motor control
Response (Lenze setting printed in bold) Setting: C00588 (; Adjustable response)
: None ; Fault  Trouble  TroubleQuickstop ; Warning  WarningLocked  Information
Cause Remedy
Maximum speed for chopper frequency has been
reached.
• The maximum speed has been exceeded depending
on the switching frequency.
Select the correct maximum speed as a function of the
switching frequency.
Defining current and speed limits
Response (Lenze setting printed in bold) Setting: C00570/1 (; Adjustable response)
: None ; Fault  Trouble  TroubleQuickstop ; Warning  WarningLocked  Information
Cause Remedy
Direct-axis current controller limitation is active. • Observe load requirements.
• Correct dimensioning or reduce setpoint generation
dynamics if necessary.
Motor control
