Lenze E84AVHC Series - Ck01: Pos. HW limit switch [xx.0184.00001]; Ck02: Neg. HW limit switch [xx.0184.00002]; Ck03: Pos. SW limit position [xx.0184.00007]; Ck04: Neg. SW limit position [xx.0184.00008]

Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010 L 491
8400 HighLine | Parameter setting & configuration
Diagnostics & error management
Error messages of the operating system
Ck01: Pos. HW limit switch [xx.0184.00001]
Ck02: Neg. HW limit switch [xx.0184.00002]
Ck03: Pos. SW limit position [xx.0184.00007]
Ck04: Neg. SW limit position [xx.0184.00008]
Ck14: Target position outside travel range limit [xx.0184.00015]
Response (Lenze setting printed in bold) Setting: C00595/1 (; Adjustable response)
; None ; Fault  Trouble : TroubleQuickstop ; Warning ; WarningLocked ; Information
Cause Remedy
MCK: The hardware limit switch in positive traversing
direction has tripped.
•The bLimitSwitchPos input for travel range
monitoring via positive hardware limit switch has
been set to FALSE (fail-safe).
Reset error message and retract limit switch.
Response (Lenze setting printed in bold) Setting: C00595/2 (; Adjustable response)
; None ; Fault  Trouble : TroubleQuickstop ; Warning ; WarningLocked ; Information
Cause Remedy
MCK: The hardware limit switch in negative traversing
direction has tripped.
•The bLimitSwitchNeg input for travel range
monitoring via negative hardware limit switch has
been set to FALSE (fail-safe).
Reset error message and retract limit switch.
Response (Lenze setting printed in bold) Setting: C00595/3 (; Adjustable response)
; None ; Fault  Trouble : TroubleQuickstop ; Warning ; WarningLocked ; Information
Cause Remedy
MCK: The device has detected that the position is beyond
the positive software limit position (C01229/1
).
• Enlarge permissible traversing range (change settings
of the software limit positions).
• Deactivate software limit position monitoring.
Response (Lenze setting printed in bold) Setting: C00595/4 (; Adjustable response)
; None ; Fault  Trouble : TroubleQuickstop ; Warning ; WarningLocked ; Information
Cause Remedy
MCK: The device has detected that the position is beyond
the negative software limit position (C01229/2
).
• Enlarge permissible traversing range (change settings
of the software limit positions).
• Deactivate software limit position monitoring.
Response (Lenze setting printed in bold) Setting: C00595/14 (; Adjustable response)
; None ; Fault  Trouble ; TroubleQuickstop ; Warning : WarningLocked ; Information
Cause Remedy
MCK: A target beyond the software limit positions
(C01229/1
and C01229/2) has been attempted to
position to.
• Select a target within the software limit positions.
• Enlarge permissible traversing range (change settings
of the software limit positions).
• Deactivate software limit position monitoring.
