8400 HighLine | Parameter setting & configuration
Technology applications
TA "Table positioning"
304 L Firmware 05.00 - DMS 4.2 EN - 02/2010
7.5.2.1 Control words wCANDriveControl/wMCIDriveControl
The control of the drive controller by a master control (e.g. IPC) is executed via the control
word wCanDriveControl or wMCIDriveControl.
wCANDriveControl: Control word via system bus (CAN)
The process data word is provided at the wCANDriveControl input via the upstream
LP_CanIn1
port block.
Display parameter: C00136/2
wMCIDriveControl: Control word via a plugged-in communication module (e.g.
PROFIBUS)
The process data word is provided at the wMCIDriveControl input via the upstream
LP_MciIn1
port block.
Display parameter: C00136/1
The bit assignment of the control words wCanDriveControl/wMCIDriveControl can be
found in the following table.
Bit Name Function
Bit 0 SwitchOn 1 Change to the "SwitchedON
" device state
This bit must be set in the CAN/MCI control word to ensure that the device
changes to the "SwitchedON
" device state after mains connection without
the need for a master control specifying this bit via fieldbus.
If control via a bus system is not wanted (e.g. in the case of control via
terminals), the wDriveCtrl output signal of the LS_ParFix
system block can be
connected to the control word inputs.
Bit 1 DisableVoltage 1 Inhibit inverter control (IMP - pulse inhibit)
Bit 2 SetQuickStop 1 Activate quick stop (QSP).
Activate/Deactivate quick stop
( 73)
Bit 3 EnableOperation 1 Enable controller (RFR)
If control via terminals is performed, this bit must be set both in the CAN
control word and in the MCI control word. Otherwise, the controller is
inhibited.
Enable/Inhibit controller
( 72)
Bit 4 ModeSpecific_1 Reserved (currently not assigned)
Bit 5 ModeSpecific_2
Bit 6 ModeSpecific_3
Bit 7 ResetFault 1 Reset fault (trip reset)
Acknowledge fault message (if the error cause has been eliminated).
Reset error
( 74)
Bit 8 SetHalt 1 Activate stop function
Stop drive via stopping ramp (in preparation).
Bit 9 reserved_1 Reserved (currently not assigned)
Bit 10 reserved_2
Bit 11 SetDCBrake 1 Activate DC-injection braking
Manual DC-injection braking (DCB)
( 175)
* Bit 12 JogSpeed1 Activation of fixed speed 1 ... 3
* Bit 13 JogSpeed2
Bit 14 SetFail 1 Set error (trip set)
* Bit 15 SetSpeedCcw 0 Direction of rotation to the right (Cw)
1 Direction of rotation to the left (Ccw)
* Assignment depends on the selected technology application
