Firmware 05.00 - DMS 4.2 EN - 02/2010 L 765
8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C01138
C01138
C01139
C01140
Parameter | Name:
C01138 | L_Transient 1-4: Function
Data type: UNSIGNED_8
Index: 23437
d
= 5B8D
h
As of version 04.00.00
Selection of edge evaluation
Selection list
0HIGH edge
1LOW edge
2HIGH and LOW edge
Subcodes Lenze setting Info
C01138/1 0: HIGH edge L_Transient_1
: Function
C01138/2 0: HIGH edge L_Transient_2
: Function
C01138/3 0: HIGH edge L_Transient_3
: Function
C01138/4 0: HIGH edge L_Transient_4
: Function
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C01139 | L_Transient 1-4: Pulse duration
Data type: UNSIGNED_16
Index: 23436
d
= 5B8C
h
As of version 04.00.00
Setting range (min. value | unit | max. value)
0.000 s 60.000
Subcodes Lenze setting Info
C01139/1 0.000 s L_Transient_1
: Pulse duration
C01139/2 0.000 s L_Transient_2
: Pulse duration
C01139/3 0.000 s L_Transient_3
: Pulse duration
C01139/4 0.000 s L_Transient_4
: Pulse duration
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1000
Parameter | Name:
C01140 | L_Transient 5-8: Function
Data type: UNSIGNED_8
Index: 23435
d
= 5B8B
h
Selection of edge evaluation
Selection list
0HIGH edge
1LOW edge
2HIGH and LOW edge
Subcodes Lenze setting Info
C01140/1 0: HIGH edge L_Transient_5
: Function
C01140/2 0: HIGH edge L_Transient_6
: Function
C01140/3 0: HIGH edge L_Transient_7
: Function
C01140/4 0: HIGH edge L_Transient_8
: Function
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
