8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00631
684 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
C00631
C00632
C00633
Parameter | Name:
C00631 | L_LimitPhi 1-3: Min/Max
Data type: INTEGER_32
Index: 23944
d
= 5D88
h
Setting the limits
Setting range (min. value | unit | max. value)
-2147483647 Incr. 2147483647
Subcodes Lenze setting Info
C00631/1 -2147483647 incr. L_LimitPhi_1
: Min.Limit
C00631/2 2147483647 incr. L_LimitPhi_1
: Max.Limit
C00631/3 -2147483647 incr. L_LimitPhi_2
: Min.Limit
C00631/4 2147483647 incr. L_LimitPhi_2
: Max.Limit
C00631/5 -2147483647 incr. L_LimitPhi_3
: Min.Limit
C00631/6 2147483647 incr. L_LimitPhi_3
: Max.Limit
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C00632 | L_NSet_1: Max.SkipFrq.
Data type: INTEGER_16
Index: 23943
d
= 5D87
h
Maximum limit values for the speed blocking zones
• Selection of the maximum limit values for the blocking zones in which the speed must not be constant.
Setting range (min. value | unit | max. value)
0.00 % 199.99
Subcodes Lenze setting Info
C00632/1 0.00 % L_NSet_1
: Blocking speed 1 max
C00632/2 0.00 % L_NSet_1
: Blocking speed 2 max
C00632/3 0.00 % L_NSet_1
: Blocking speed 3 max
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C00633 | L_NSet_1: Min.SkipFrq.
Data type: INTEGER_16
Index: 23942
d
= 5D86
h
Minimum limit values for the speed blocking zones
• Selection of the minimum limit values for the blocking zones in which the speed must not be constant.
Setting range (min. value | unit | max. value)
0.00 % 199.99
Subcodes Lenze setting Info
C00633/1 0.00 % L_NSet_1: Blocking speed 1 min
C00633/2 0.00 % L_NSet_1
: Blocking speed 2 min
C00633/3 0.00 % L_NSet_1
: Blocking speed 3 min
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
