8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00833
720 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
C00833
C00832/84 LS_DataAccess: wIn2
(Lenze-internal)
C00832/85 LS_DataAccess: wIn3
(Lenze-internal)
C00832/86 LS_DataAccess: wIn4
(Lenze-internal)
C00832/87 L_PT1_1
: nIn_a
C00832/88 MCTRL
: nSpeedHighLimit_a
C00832/89 L_PCTRL_1
: nNSet_a
C00832/90 L_PCTRL_1
: nISet_a
C00832/91 L_Interpolator_1
: nPhdIn_v
C00832/92 L_Interpolator_1
: nNIn_a
C00832/93 Reserved
C00832/94 Reserved
C00832/95 Reserved
; Read access Write access CINH PLC STOP ; No transfer COM MOT Scaling factor: 1
Parameter | Name:
C00832 | 16bit input velocity
Data type: INTEGER_16
Index: 23743
d
= 5CBF
h
Parameter | Name:
C00833 | 8bit input
Data type: UNSIGNED_8
Index: 23742
d
= 5CBE
h
Display of the signal status of the binary inputs of different blocks
Selection list
0 False
1 True
Subcodes Info
C00833/1 L_And_1
: bIn1
C00833/2 L_And_1
: bIn2
C00833/3 L_And_1
: bIn3
C00833/4 L_DFlipFlop_1: bD
(set input)
C00833/5 L_DFlipFlop_1
: bClk
(clock input)
C00833/6 L_DFlipFlop_1
: bClr
(reset input)
C00833/7 L_Not_1
: bIn
C00833/8 L_Or_1
: bIn1
C00833/9 L_Or_1
: bIn2
C00833/10 L_Or_1
: bIn3
C00833/11 L_RLQ_1
: bCw
(CW rotation)
C00833/12 L_RLQ_1
: bCcw
(CCW rotation)
C00833/13 L_AnalogSwitch_1
: bSet
(switch over analog values)
C00833/14 L_NSet_1
: bRfgStop
(stop ramp function generator)
C00833/15 L_NSet_1
: bRfg0
(reset ramp function generator)
