Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010 L 783
8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C01298
C01298
C01299
Parameter | Name:
C01298 | MCK: Change of operating mode with profile no.
Data type: UNSIGNED_8
Index: 23277
d
= 5AED
h
FB L_MckCtrlInterface_1: Assigning an operating mode to a profile
Selection list Info
0 No change No change to another operating mode of the MCK
1 Follower Change to the "Speed follower" mode
2 Homing Change to the "Homing" mode
3 ManualJog Change to the "Manual jog" mode
4 Positioning Change to the "Positioning" mode
Subcodes Lenze setting Info
C01298/1 1: Follower MCK operating mode at profile no. 0
• Selection of the operating mode for profile 0 at
L_MckCtrlInterface_1.
C01298/2 2: Homing MCK operating mode at profile no. 1
• Selection of the operating mode for profile 1 at
L_MckCtrlInterface_1.
C01298/3 3: ManualJog MCK operating mode at profile no. 2
• Selection of the operating mode for profile 2 at
L_MckCtrlInterface_1.
C01298/4 4: Positioning MCK operating mode at profile no. 3...15
• Selection of the operating mode for profile 3 ... 15 at
L_MckCtrlInterface_1.
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C01299 | MCKI: MCKInterface status
Data type: UNSIGNED_8
Index: 23276
d
= 5AEC
h
FB L_MckCtrlInterface_1: Status messages
Display area (min. hex value | max. hex value)
0x00 0xFF
Value is bit-coded: Info
Bit 0 InvalidOperationMode Invalid operating mode selection
•"1" ≡ The selected operating mode is not defined/
invalid.
Bit 1 InvalidPosMode Invalid positioning mode selection
•"1" ≡ The selected positioning mode is not defined/
invalid.
Bit 2 InvalidProfileNo Invalid profile number selection
•"1" ≡ The selected profile number refers to a profile
data set that does not exist.
Bit 3 Reserved
Bit 4 Reserved
Bit 5 Reserved
Bit 6 Reserved
Bit 7 Reserved
; Read access Write access CINH PLC STOP ; No transfer COM MOT
