Lenze E84AVHC Series - C00622 | System connection list: Angle; C00630 | L_Limit 1-2: Min;Max

Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010 L 683
8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00622
C00622
C00630
Parameter | Name:
C00622 | System connection list: Angle
Data type: UNSIGNED_16
Index: 23953
d
= 5D91
h
Connection parameters: 32-bit inputs
• Selection of the 32-bit output signals for connection with the 32-bit input signals.
• The selection list contains all 32-bit output signals which can be assigned to the 32-bit inputs mapped by the
subcodes.
Selection list
See selection list - angle signals
Subcodes Lenze setting Info
C00622/1 0: Not connected LS_DisFree_p
:dnDis1_p
C00622/2 0: Not connected LS_DisFree_p
:dnDis2_p
C00622/3 0: Not connected LS_DisFree_p
: dnDis3_p
C00622/4 0: Not connected LS_DisFree_p
: dnDis4_p
C00622/5 0: Not connected LS_DisFree_p
: dnDis5_p
C00622/6 0: Not connected LS_DisFree_p
: dnDis6_p
C00622/7 0: Not connected LS_DisFree_p
: dnDis7_p
C00622/8 0: Not connected LS_DisFree_p
: dnDis8_p
C00622/9 0: Not connected LP_CanOut1
: dnOut34_p
C00622/10 0: Not connected LP_CanOut2
: dnOut34_p
C00622/11 0: Not connected LP_CanOut3
: dnOut34_p
C00622/12 0: Not connected LP_MciOut
: dnOut34_p
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00630 | L_Limit 1-2: Min/Max
Data type: INTEGER_16
Index: 23945
d
= 5D89
h
Setting the limits
Setting range (min. value | unit | max. value)
-199.99 % 199.99
Subcodes Lenze setting Info
C00630/1 -199.99 % L_Limit_1
: Min.Limit
C00630/2 199.99 % L_Limit_1: Max.Limit
C00630/3 -199.99 % L_Limit_2
: Min.Limit
C00630/4 199.99 % L_Limit_2
: Max.Limit
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
