Lenze E84AVHC Series User Manual

Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010 L 785
8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C01303
C01303
C01304
C01305
Parameter | Name:
C01303 | Profile data: Acceleration
Data type: INTEGER_32
Index: 23272
d
= 5AE8
h
Selection of the accelerations for profiles 1 ... 15
Profile entry
Setting range (min. value | unit | max. value)
-214748.3647 unit/s2 214748.3647
Subcodes Lenze setting Info
C01303/1 720.0000 unit/s2 Profiles 1 ... 15: Acceleration
C01303/...
C01303/15
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10000
Parameter | Name:
C01304 | Profile data: Deceleration
Data type: INTEGER_32
Index: 23271
d
= 5AE7
h
Selection of the decelerations for profiles 1 ... 15
Profile entry
Setting range (min. value | unit | max. value)
-214748.3647 unit/s2 214748.3647
Subcodes Lenze setting Info
C01304/1 720.0000 unit/s2 Profiles 1 ... 15: Deceleration
C01304/...
C01304/15
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10000
Parameter | Name:
C01305 | Profile data: Final speed
Data type: INTEGER_32
Index: 23270
d
= 5AE6
h
Selection of the final speeds for profiles 1 ... 15
• For profile linkage with overchange.
Profile entry
Setting range (min. value | unit | max. value)
-214748.3647 unit/s 214748.3647
Subcodes Lenze setting Info
C01305/1 0.0000 unit/s Profiles 1 ... 15: Final speed
C01305/...
C01305/15
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10000
