Lenze E84AVHC Series - C00720 | L_DigitalDelay_1: Delay; C00721 | L_DigitalDelay 2,3: Delay; C00725 | Current switching frequency

Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010 L 701
8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00720
C00720
C00721
C00725
Parameter | Name:
C00720 | L_DigitalDelay_1: Delay
Data type: UNSIGNED_32
Index: 23855
d
= 5D2F
h
Switch-on/off delay time
Setting range (min. value | unit | max. value)
0.000 s 3600.000
Subcodes Lenze setting Info
C00720/1 0.000 s L_DigitalDelay_1
: On delay
C00720/2 0.000 s L_DigitalDelay_1
: Off delay
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1000
Parameter | Name:
C00721 | L_DigitalDelay 2,3: Delay
Data type: UNSIGNED_32
Index: 23854
d
= 5D2E
h
Switch-on/off delay time
Setting range (min. value | unit | max. value)
0.000 s 3600.000
Subcodes Lenze setting Info
C00721/1 0.000 s L_DigitalDelay_2
: On delay
C00721/2 0.000 s L_DigitalDelay_2
: Off delay
C00721/3 0.000 s L_DigitalDelay_3
: On delay
C00721/4 0.000 s L_DigitalDelay_3
: Off delay
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1000
Parameter | Name:
C00725 | Current switching frequency
Data type: UNSIGNED_8
Index: 23850
d
= 5D2A
h
Display of the current switching frequency
•In C00018
you can choose between a drive-optimised setting for good smooth-running characteristics and an
inverter loss-optimised setting (min. Pv).
• For these options, you can, in turn, choose between fixed and variable switching frequencies.
• When a variable switching frequency is selected in C00018
, the switching frequency may change as a function
of the load and rotational frequency.
Selection list (read only)
1 4 kHz var./drive-optimised
2 8 kHz var./drive-optimised
3 16 kHz var./drive-optimised
5 2 kHz constant/drive-optimised
6 4 kHz constant/drive-optimised
7 8 kHz constant/drive-optimised
8 16 kHz constant/drive-optimised
11 4 kHz var./min. Pv
12 8 kHz var./min. Pv
13 16 kHz var./min. Pv
14 Reserved
15 2 kHz constant/min. Pv
16 4 kHz constant/min. Pv
17 8 kHz constant/min. Pv
18 16 kHz constant/min. Pv
; Read access  Write access  CINH  PLC STOP ; No transfer  COM  MOT Scaling factor: 1
