Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010 L 657
8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00443
C00443
Parameter | Name:
C00443 | DIx: level
Data type: UNSIGNED_16
Index: 24132
d
= 5E44
h
Bit-coded display of the level of the digital inputs
Digital input terminals
Display area (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded: Info
Bit 0 DI1 Bit set = HIGH level
Bit 1 DI2
Bit 2 DI3
Bit 3 DI4
Bit 4 DI5
Bit 5 DI6
Bit 6 DI7
Bit 7 Reserve
Bit 8 Reserve
Bit 9 Reserve
Bit 10 Reserve
Bit 11 Reserve
Bit 12 Reserve
Bit 13 Reserve
Bit 14 Reserve
Bit 15 CINH
Subcodes Info
C00443/1 DIx: Terminal level
C00443/2 DIx: Output level
; Read access Write access CINH PLC STOP ; No transfer COM MOT
