8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C01141
766 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
C01141
C01150
C01151
C01202
Parameter | Name:
C01141 | L_Transient 5-8: Pulse duration
Data type: UNSIGNED_16
Index: 23434
d
= 5B8A
h
Setting range (min. value | unit | max. value)
0.000 s 60.000
Subcodes Lenze setting Info
C01141/1 0.000 s L_Transient_5
: Pulse duration
C01141/2 0.000 s L_Transient_6
: Pulse duration
C01141/3 0.000 s L_Transient_7
: Pulse duration
C01141/4 0.000 s L_Transient_8
: Pulse duration
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1000
Parameter | Name:
C01150 | L_PhaseIntK: Function
Data type: UNSIGNED_8
Index: 23425
d
= 5B81
h
Loading behaviour of the integrator
Selection list Info
0 Loading with level Load integrator with TRUE level at the input bLoad
1 Loading with edge Load integrator with FALSE/TRUE edge at the input
bLoad
2 Loading with level + reset Load integrator when reaching the comparison value
(C01151
) or with TRUE level at the input bLoad
Subcodes Lenze setting Info
C01150/1 0: Loading with level L_PhaseIntK_1
: Function
C01150/2 0: Loading with level L_PhaseIntK_2
: Function
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C01151 | L_PhaseIntK: Compare
Data type: INTEGER_32
Index: 23424
d
= 5B80
h
Comparison value
Setting range (min. value | unit | max. value)
0 2000000000
Subcodes Lenze setting Info
C01151/1 0 L_PhaseIntK_1
: Compare
C01151/2 0 L_PhaseIntK_2: Compare
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C01202 | Axis data: iM motor/process
Data type: UNSIGNED_16
Index: 23373
d
= 5B4D
h
Gearbox factor - motor
• Entry of the gearbox factor as numerator/denominator ratio (numerator = motor speed and denominator =
output speed of gearbox) or from the number of teeth of the gearbox arrangement.
Machine parameter
Setting range (min. value | unit | max. value)
1 65535
Subcodes Lenze setting Info
C01202/1 1 iM: Numerator (motor speed Z2xZ4)
C01202/2 1 iM: Denominator (system speed Z1xZ3)
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
