Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010 L 85
8400 HighLine | Parameter setting & configuration
Device control (DCTRL)
Device states
4.2.10 Trouble
This device state becomes active as soon as a monitoring mode responds for which the
error response "Trouble" has been parameterised.
The motor has no torque (is coasting) due to the inhibit of the inverter.
The "Trouble" device state is automatically abandoned if the error cause has been
removed.
Depending on certain conditions a state change takes place based on the "Trouble" device
state.
Related topics:
wCANControl/wMCIControl control words
( 94)
Basics on error handling in the controller
( 452)
Error messages of the operating system
( 471)
LED DRIVE READY LED DRIVE ERROR Display in C00137 Display in status word 1 (C00150)
Bit 11 Bit 10 Bit 9 Bit 8
Off Trouble 0111
Note!
If the "Inhibit at trouble" auto-start option has been activated in C00142, explicit
deactivation of the controller inhibit is required before this state can be
abandoned.
Change condition Changeover to the device state
The error cause is no longer active. ReadyToSwitchON
Control bit "EnableOperation" of all control channels = "1"
AND terminal RFR = HIGH level (controller enable)
AND the message has been cancelled.
OperationEnabled
Control bit "EnableOperation" of a control channel = "0"
OR terminal RFR = LOW level (controller inhibit)
AND the message has been cancelled.
SwitchedON
In the system, there is an error configured on "TroubleQSP".
AND the message has been cancelled.
TroubleQSP
