8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00990
C00990
C00991
C00992
C00993
C00994
Parameter | Name:
C00990 | Flying restart fct: Activation
Data type: UNSIGNED_8
Index: 23585
d
= 5C21
h
Switch on /activate flying restart circuit for non-feedback drive systems
Flying restart function
Selection list (Lenze setting printed in bold)
0Off
1On
; Read access ; Write access ; CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00991 | Flying restart fct: Process
Data type: UNSIGNED_16
Index: 23584
d
= 5C20
h
Selection of the starting value and the speed search range for the flying restart function
Flying restart function
Selection list (Lenze setting printed in bold) Info
0 0...+n | Start: +10 Hz Search positive speed range (0 ... +n) with a start
frequency of +10 Hz
1 -n...0 | Start: -10 Hz Search negative speed range (-n ... 0) with a start
frequency of -10 Hz
2 -n...+n | Start: +10 Hz Search negative and positive speed range (-n ... n) with a
start frequency of +10 Hz
3 -n...+n | Start: -10 Hz Search negative and positive speed range (-n ... n) with a
start frequency of -10 Hz
4 -n...+n | Start: Cx992 Search negative and positive speed range (-n ... n) with
the start frequency set in C00992
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00992 | Flying restart: Start frequency
Data type: INTEGER_16
Index: 23583
d
= 5C1F
h
Manual selection of the starting value for the flying restart function
•Only active if C00991
= 4
Flying restart function
Setting range (min. value | unit | max. value) Lenze setting
-200 Hz 200 10 Hz
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00993 | Flying restart fct: Int. time
Data type: UNSIGNED_16
Index: 23582
d
= 5C1E
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00994 | Flying restart fct: Current
Data type: INTEGER_16
Index: 23581
d
= 5C1D
h
Current to be injected during the flying restart process
•100% ≡ rated motor current (C00081
).
• The flying restart current should amount to 10 ... 25 % of the rated motor current.
Flying restart function
Setting range (min. value | unit | max. value) Lenze setting
0.00 % 100.00 25.00 %
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
