8400 HighLine | Parameter setting & configuration
Device control (DCTRL)
Device states
86 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
4.2.11 Fault
This device state will be active as soon as a monitoring mode responds, the error response
"Fault" has been parameterised for.
The motor has no torque (is coasting) due to the inhibit of the inverter.
The error must explicitly be reset ("acknowledged") in order to exit the device state, e.g.
by the device command "Reset error
" or via the control bit "ResetFault" in the control
word wCanControl or wMCIControl.
Related topics:
wCANControl/wMCIControl control words
( 94)
Basics on error handling in the controller
( 452)
Error messages of the operating system
( 471)
4.2.12 SystemFault
This device state becomes active if a system fault occurs.
The device state can only be abandoned by
–mains switching or
– a system restart (in preparation).
LED DRIVE READY LED DRIVE ERROR Display in C00137 Display in status word 1 (C00150)
Bit 11 Bit 10 Bit 9 Bit 8
Off Fault 1000
Note!
If an undervoltage in the DC bus of the drive controller occurs (error message
"LU"), the device changes to the "Trouble
" state.
An additional error of higher priority leads the device into the "Fault
" state.
According to the Device state machine
, the device changes to the
"ReadyToSwitchON
" state after acknowledging the error although the
undervoltage is still available!
If the "Inhibit at fault" auto-start option has been activated in C00142
, explicit
deactivation of the controller inhibit is required before the state can be
abandoned.
LED DRIVE READY LED DRIVE ERROR Display in C00137 Display in status word 1 (C00150)
Bit 11 Bit 10 Bit 9 Bit 8
Off SystemFault 1011
