8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00052
598 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
C00052
C00053
C00054
C00056
C00057
C00058
Parameter | Name:
C00052 | Motor voltage
Data type: UNSIGNED_16
Index: 24523
d
= 5FCB
h
Display of the current motor voltage/output voltage of the inverter
Display range (min. value | unit | max. value)
0 V 1000
; Read access  Write access  CINH  PLC STOP ; No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00053 | DC-bus voltage
Data type: UNSIGNED_16
Index: 24522
d
= 5FCA
h
Display of the current DC-bus voltage
Display range (min. value | unit | max. value)
0 V 1000
; Read access  Write access  CINH  PLC STOP ; No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00054 | Motor current
Data type: UNSIGNED_16
Index: 24521
d
= 5FC9
h
Display of the current motor current/output current of the inverter
Display range (min. value | unit | max. value)
0.00 A 300.00
; Read access  Write access  CINH  PLC STOP ; No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00056 | Torque
Data type: INTEGER_32
Index: 24519
d
= 5FC7
h
Display of the current torque
Display range (min. value | unit | max. value)
-65000.00 Nm 65000.00
Subcodes Info
C00056/1 Torque setpoint
• Only for SLVC and SC modes.
C00056/2 Actual torque
• Estimated actual torque for all operating modes.
; Read access  Write access  CINH  PLC STOP ; No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00057 | Maximum torque
Data type: UNSIGNED_32
Index: 24518
d
= 5FC6
h
Display of the maximum torque to be generated by the motor
• The maximum torque to be generated by the motor depends on various factors, e.g. on Imax in motor mode
(C00022
) and the motor type used.
Display range (min. value | unit | max. value)
0.00 Nm 65000.00
; Read access  Write access  CINH  PLC STOP ; No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00058 | Output frequency
Data type: INTEGER_32
Index: 24517
d
= 5FC5
h
Display of the current output frequency
Display range (min. value | unit | max. value)
-1300.00 Hz 1300.00
; Read access  Write access  CINH  PLC STOP ; No transfer  COM  MOT Scaling factor: 100
