Firmware 05.00 - DMS 4.2 EN - 02/2010 L 759
8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C01023
C01023
C01040
C01041
C01042
Parameter | Name:
C01023 | L_Odometer_1: Edge selection
Data type: UNSIGNED_8
Index: 23552
d
= 5C00
h
As of version 04.00.00
L_Odometer_1
FB: Selection of the edge that trips the measurement
Selection list (Lenze setting printed in bold)
0HIGH edge
1LOW edge
2HIGH and LOW edge
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C01040 | L_SRFG_1..2: Linear ramp time
Data type: UNSIGNED_32
Index: 23535
d
= 5BEF
h
As of version 04.00.00
Symmetrical acceleration/deceleration time for the ramp function generator
Setting range (min. value | unit | max. value)
0.001 s 999.999
Subcodes Lenze setting Info
C01040/1 100.000 s L_SRFG_1
: Linear ramp time
C01040/2 100.000 s L_SRFG_2
: Linear ramp time
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1000
Parameter | Name:
C01041 | L_SRFG_1..2: S-ramp time
Data type: UNSIGNED_32
Index: 23534
d
= 5BEE
h
As of version 04.00.00
S-ramp time for jerk-free acceleration
Setting range (min. value | unit | max. value)
0.001 s 50.000
Subcodes Lenze setting Info
C01041/1 0.200 s L_SRFG_1
: S-ramp time
C01041/2 0.200 s L_SRFG_2: S-ramp time
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1000
Parameter | Name:
C01042 | L_SRFG_1..2 limitations of output values
Data type: INTEGER_16
Index: 23533
d
= 5BED
h
As of version 05.00.00
Limitation of the output values
Setting range (min. value | unit | max. value)
-199.99 % 199.99
Subcodes Lenze setting Info
C01042/1 100.00 % L_SRFG_1
: Pos. Limit
C01042/2 -100.00 % L_SRFG_1
: Neg. Limit
C01042/3 100.00 % L_SRFG_2
: Pos. Limit
C01042/4 -100.00 % L_SRFG_2
: Neg. Limit
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
