Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010 L 941
8400 HighLine | Parameter setting & configuration
Function library
Function blocks | L_Curve_1
14.1.54.1 Function 2: nOut_a = f(x)
Function in preparation!
If function 2 has been selected in C00960
, the output value is calculated according to the
following formula which can be used to display both lines (including offsets) and non-
linear functions:
[14-21] Equation for function 2: nOut_a = f(x)
C00962/1...4 -32767 32767 In preparation!
a0 ... a3 coefficients
• For function nOut_a = f(x)
• Lenze setting: 0
Function 2: nOut_a = f(x)
C00963/1...32 -32767 32767 X values for characteristic function
• Subcodes 1 ... 32 correspond to
interpolation point values
X1 ... X32.
• Lenze setting: 0
Function 3: nOut_a = f(table)
C00964/1...32 -32767 32767 Y values for characteristic function
• Subcodes 1 ... 32 correspond to
interpolation point values
Y1 ... Y32.
• Lenze setting: 0
Function 3: nOut_a = f(table)
Parameter Possible settings Info
a0 = C00962/1
a1 = C00962/2
a2 = C00962/3
a3 = C00962/4
nOut_a a3 nIn_a
3
⋅ a2 nIn_a
2
⋅ a1 nIn_a⋅ a0+++=
