7.7.2 Arithmetic
This funciton links two analog signals arithmetically. The arithmetic function can be
parameterised.
[7-2] GeneralPurpose function "Arithmetic"
For a detailed functional description see FB L_Arithmetic.
7.7.3 Multiplication/Division
This function multiplies an analog input signal with a parameterisable factor. The factor
must be selected in the form of a quotient (numerator and denominator).
[7-3] GeneralPurpose function "Multiplication/division"
For a detailed functional description see FB L_MulDiv.
nGPArithmetikOut_a
nGPArithmetikIn1_a
nGPArithmetikIn2_a
C00830/12
C00830/13
(In1 * 100%)5
(In1 * In2)3
(In1 * 1%)4
In1 - In22
In1 + In21
In10
C00338
100%
|In2|
(100% - In2)
In1
In2
Out =
±32767
(±199.99%)
Parameter Info Lenze setting
Value Unit
C00338 L_Arithmetik_1: function 0: nOut_a = nIn1_a
nGPMulDivIn_a nGPMulDivOut_a
C00699/1
C00699/2
C00830/82
±32767
±( 199.99%)
Parameter Info Lenze setting
Value Unit
C00699/1 L_MulDiv_1: Numerator 0
C00699/2
L_MulDiv_1: Denominator 10000
