Lenze E84AVHC Series User Manual

Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010 L 493
8400 HighLine | Parameter setting & configuration
Diagnostics & error management
Error messages of the operating system
Ck11: Invalid operating mode [xx.0184.08009]
Ck12: Invalid profile number [xx.0184.08014]
Ck13: Error - MCKCtrlInterface function block [xx.0184.08015]
dH09: EEPROM power section [xx.0400.00009]
dH10: Fan failure [xx.0400.00016]
dH69: Adjustment fault [xx.0400.00105]
Response (Lenze setting printed in bold) Setting: C00595/11 (; Adjustable response)
; None ; Fault  Trouble ; TroubleQuickstop : Warning ; WarningLocked ; Information
Cause Remedy
MCK: The operating mode defined via the
wMckOperationMode input is not supported.
Define a valid operating mode.
Response (Lenze setting printed in bold) Setting: C00595/12 (; Adjustable response)
; None ; Fault  Trouble ; TroubleQuickstop ; Warning : WarningLocked ; Information
Cause Remedy
MCK: The positioning profile number in the positioning
operating mode specified via the wPosProfileNo input is
invalid.
Define a valid profile number.
Response (Lenze setting printed in bold) Setting: C00595/13 (; Adjustable response)
; None ; Fault  Trouble ; TroubleQuickstop : Warning ; WarningLocked ; Information
Cause Remedy
MCK: An error has occurred in the L_MckCtrlInterface_1
function block.
Check wiring and parameterisation of the
L_MckCtrlInterface_1
function block.
Response (Lenze setting printed in bold)
 None : Fault  Trouble  TroubleQuickstop  Warning  WarningLocked  Information
Cause Remedy
Device error Consultation with Lenze required.
Response (Lenze setting printed in bold) Setting: C00566 (; Adjustable response)
; None ; Fault  Trouble  TroubleQuickstop : Warning  WarningLocked  Information
Cause Remedy
The device fan has failed.
Possible causes:
• The short-circuit check of the fan connection has
tripped.
• The speed monitoring of the fan has tripped.
• Check the fan for short-circuit.
•Clean the fan.
Response (Lenze setting printed in bold)
 None : Fault  Trouble  TroubleQuickstop  Warning  WarningLocked  Information
Cause Remedy
Device error Consultation with Lenze required.
