Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010 L 1095
8400 HighLine | Parameter setting & configuration
Function library
System blocks | LS_WriteParamList
Importing/exporting the list
For cross-device
reuse of the configured WriteParamList, you can click on the Export list and
Import list buttons to save the parameter selection as an *.epc file and then to re-import
the saved *.epc file into another drive controller 8400.
14.2.26.2 Configuring the list by means of parameterisation
The following application example shows the necessary procedure for configuring the list
without
using the »Engineer« parameterisation dialog.
Task:
Using the LS_WriteParamList SB, the C00012, C00026/1, C00027/1, and C00222 to C00224
parameters are to be written.
Compiling the parameter list
In C01085/1 ... n
, specify the above-named parameters in the <Code>,<Subcode> format:
C01085/1
= 12,000
C01085/2
= 26,001
C01085/3
= 27,001
C01085/4
= 222,000
C01085/5
= 223,000
C01085/6
= 224,000
C01085/7 ... n
= 0,000 (no parameter)
Entering values for the parameters (value set 1)
In C01086/1 ... n
, specify the values to be used to describe the selected parameters:
C01086/1
= <value> for list entry 1 (in our example: for parameter C00012)
C01086/2
= <value> for list entry 2 (in our example: for parameter C00026/1)
C01086/3
= <value> for list entry 3 (in our example: for parameter C00027/1)
etc.
These values are used in the writing process if the two bSelectWriteValue_1 and
bSelectWriteValue_2 inputs are not assigned or both set to FALSE.
Entering other values for the parameters (value sets 2 ... 4)
If required, up to three other sets can be set in the same way in C01087/1 ... n
to C01089/
1 ... n which can optionally be written to the parameters. The decision as to which value set
Note!
Gaps in the parameter list (setting = 0,000) are permissible and are skipped
during the process.
