8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00496
666 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
C00496
C00497
C00516
Parameter | Name:
C00496 | Encoder evaluation procedure
Data type: UNSIGNED_8
Index: 24079
d
= 5E0F
h
Encoder/feedback system
Selection list (Lenze setting printed in bold) Info
0 High-resolution encoders High-precision procedure for high-resolution encoders
(>=512 increments)
1 Low-res. encoders (StateLine) High-precision procedure for low-resolution encoders
(<=128 increments)
2 Comb. encoder procedure Combination of the first two procedures as a function of
the speed (recommended procedure)
3 Edge counting procedure Simple edge counting procedure with adjustable scan
time (C00425
)
; Read access ; Write access ; CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00497 | Nact filter time constant
Data type: UNSIGNED_16
Index: 24078
d
= 5E0E
h
As of version 03.00.00
Encoder/feedback system
Setting range (min. value | unit | max. value)
0.0 ms 500.0
Subcodes Lenze setting Info
C00497/1 1.0 ms Encoder filter time FreqIn12
C00497/2 1.0 ms Encoder filter time FreqIn67
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10
Parameter | Name:
C00516 | Checksums
Data type: UNSIGNED_32
Index: 24059
d
= 5DFB
h
This code is for device-internal use only and must not be written to by the user!
