Lenze E84AVHC Series User Manual

8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00803
706 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
C00803
C00804
C00805
C00806
Parameter | Name:
C00803 | L_MPot_1: Deceleration time
Data type: UNSIGNED_16
Index: 23772
d
= 5CDC
h
FB L_MPot_1: Deceleration time of the motor potentiometer function
Setting range (min. value | unit | max. value) Lenze setting
0.1 s 6000.0 10.0 s
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10
Parameter | Name:
C00804 | L_MPot_1: Inactive function
Data type: UNSIGNED_8
Index: 23771
d
= 5CDB
h
FB L_MPot_1: Selection of the response when deactivating the motor potentiometer via the bInAct input
Selection list (Lenze setting printed in bold) Info
0 Retain value Keep output value
1 Deceleration to 0 Deceleration via ramp to 0
2 Deceleration to lower limit Deceleration via ramp to lower limit (C00801
)
3 Without ramp to 0 Jump to 0
4 Without ramp to lower limit Jump to lower limit (C00800
)
5 Acceleration to upper limit Acceleration via ramp to upper limit (C00800
)
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00805 | L_MPot_1: Init fct.
Data type: UNSIGNED_8
Index: 23770
d
= 5CDA
h
FB L_MPot_1: Selection of the response when switching on the device
Selection list (Lenze setting printed in bold)
0 Load last value
1 Load lower limit
2Load 0
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00806 | L_MPot_1: Use
Data type: UNSIGNED_8
Index: 23769
d
= 5CD9
h
FB L_MPot_1: Use of the motor potentiometer
Selection list (Lenze setting printed in bold) Info
0No The motor potentiometer is not used.
• The analog value applied to the nIn_a input is looped
through without any changes to the nOut_a output.
1 Yes The motor potentiometer is used.
• The analog value applied at the nIn_a input is led via
the motor potentiometer and provided at the nOut_a
output.
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
