Lenze E84AVHC Series User Manual

Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010 L 639
8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00342
C00342
Parameter | Name:
C00342 | CAN decoupling PDOInOut
Data type: UNSIGNED_16
Index: 24233
d
= 5EA9
h
As of version 04.00.00
Configuration defining the events that lead to a decoupling of the process data words.
"CAN on board" system bus: Configuring the exception handling of the CAN PDOs
Setting range (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded: (; =bit set)
Bit 0  BusOff_MsgErr
Bit 1  Warning
Bit 2  NodeStopped
Bit 3  HeartBeatEvent
Bit 4  CAN1_In_Monitor.
Bit 5  CAN2_In_Monitor.
Bit 6  CAN3_In_Monitor.
Bit 7  Reserved
Bit 8  Reserved
Bit 9  Reserved
Bit 10  Reserved
Bit 11  Reserved
Bit 12  Reserved
Bit 13  Reserved
Bit 14  Trouble
Bit 15  Fault
Subcodes Lenze setting Info
C00342/1 0 CAN decoupling PDO_In from the bus
C00342/2 0 CAN decoupling PDO_Out from the appl.
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT
