Lenze E84AVHC Series - C00136 | Communication control words

8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00136
610 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
C00136
Parameter | Name:
C00136 | Communication control words
Data type: UNSIGNED_16
Index: 24439
d
= 5F77
h
Control words of the communication interfaces
Display area (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded:
Bit 0 SwitchOn
Bit 1 DisableVoltage
Bit 2 SetQuickStop
Bit 3 EnableOperation
Bit 4 ModeSpecific_1
Bit 5 ModeSpecific_2
Bit 6 ModeSpecific_3
Bit 7 ResetFault
Bit 8 SetHalt
Bit 9 Reserved_1
Bit 10 Reserved_2
Bit 11 LenzeSpecific_1
Bit 12 LenzeSpecific_2
Bit 13 LenzeSpecific_3
Bit 14 SetFail
Bit 15 LenzeSpecific_4
Subcodes Info
C00136/1 MCI control word
• Control word of the communication interface MCI
(communication module)
C00136/2 CAN control word
• Control word of the communication interface CAN
(CAN on board)
; Read access  Write access  CINH  PLC STOP ; No transfer  COM  MOT
