This chapter describes the function blocks which are available for the controller in the FB
Editor.
Overview of function blocks available
The system blocks are described in the chapter "System blocks". ( 1070)
Function block Runtime Function
L_Absolute_1
L_Absolute_2
2 μs ... converts a bipolar input signal into a unipolar output signal.
L_AddSub_1
3 μs ... adds / subtracts analog input signals.
L_AnalogSwitch_1
L_AnalogSwitch_2
L_AnalogSwitch_3
L_AnalogSwitch_4
L_AnalogSwitch_5
2 μs ... switches between two analog input signals.
L_And_1
L_And_2
L_And_3
2 μs ... ANDs three binary signals.
L_And5_1
L_And5_2
2 μs ... ANDs five binary signals.
L_Arithmetik_1
L_Arithmetik_2
L_Arithmetik_3
L_Arithmetik_4
L_Arithmetik_5
7 μs ... combines two analog signals arithmetically.
L_ArithmetikPhi_1
L_ArithmetikPhi_2
L_ArithmetikPhi_3
7 μs ... combines two angle signals arithmetically.
L_Compare_1
L_Compare_2
L_Compare_3
L_Compare_4
L_Compare_5
5 μs ... compares two analog signals and can be used e.g. to implement a
trigger.
L_ComparePhi_1
L_ComparePhi_2
L_ComparePhi_3
L_ComparePhi_4
L_ComparePhi_5
5 μs... compares two angle signals.
L_ConvBitsToWord_1
L_ConvBitsToWord_2
L_ConvBitsToWord_3
3 μs ... converts 16 bit input values of the type "BOOL" into an output value of
the type "WORD".
L_ConvDIntToWords_1
L_ConvDIntToWords_2
L_ConvDIntToWords_3
3 μs ... converts an input value of the type "DINT" into two output values of
the type "WORD".
L_ConvUnitsToIncr_1
L_ConvUnitsToIncr_2
L_ConvUnitsToIncr_3
3 μs FB in preparation!
... converts a position value provided in the real unit of the machine into
an internal 32-bit position value.
