8400 HighLine | Parameter setting & configuration
Fieldbus interface
Control mode "MCI"
11.2 Control mode "MCI"
"40: MCI" can be selected as a control mode in C00007
in order to quickly and easily set-up
drive controller control by means of MCI-PDOs via the fieldbus interface.
Given that the technology applications are fundamentally different and have different
requirements regarding the signals sent to them, predefined assignment of the MCI-PDOs
depends on the technology application selected in C00005
:
 "Actuating drive speed" TA: Control mode MCI
( 284)
 "Table positioning" TA: Control mode MCI
( 317)
 "Switch-off positioning" TA: Control mode MCI
( 348)
 Tip!
The predefined assignment of the MCI-PDOs can be parameterised by means of
PDO mapping and can be freely configured on the I/O level in the function block
editor (FB editor).
