Lenze E84AVHC Series User Manual

8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00401
650 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
C00401
C00408
Parameter | Name:
C00401 | CANxInOut: Inversion
Data type: UNSIGNED_16
Index: 24174
d
= 5E6E
h
As of version 02.00.00
Via these parameters, the control and status bits of the CAN port blocks can be inverted
System bus "CAN on board": Port blocks
Setting range (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded: Info
Bit 0 Active Bit set = bit is inverted
... ...
Bit 15 Active
Subcodes Lenze setting Info
C00401/1 0 Inversion of LP_CanIn1.bCtrl1_B0...15
C00401/2 0 Inversion of LP_CanOut1.bState1_B0...15
C00401/3 0 Inversion of LP_CanIn2.bIn1_B0...15
C00401/4 0 Inversion of LP_CanOut2.bOut1_B0...15
C00401/5 0 Inversion of LP_CanIn3.bIn1_B0...15
C00401/6 0 Inversion of LP_CanOut3.bOut1_B0...15
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C00408 | LP_CanIn mapping selection
Data type: UNSIGNED_8
Index: 24167
d
= 5E67
h
As of version 02.00.00
Selection of the mapping source for port blocks LP_CanIn1...3
System bus "CAN on board": Port blocks
Selection list Info
0CanIn CanIn
1 Par.C409 Mapping configured in C00409
Subcodes Lenze setting Info
C00408/1 0: CanIn Mapping selection LP_CanIn1
C00408/2 0: CanIn Mapping selection LP_CanIn2
C00408/3 0: CanIn Mapping selection LP_CanIn3
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
