8400 HighLine | Parameter setting & configuration
Basic drive functions (MCK)
Holding brake control
442 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
8.12.2.2 Functional settings
In C02582
, the following functional settings for holding brake control can be made in bit-
coded form:
Related topics:
Response to pulse inhibit
( 449)
Torque precontrol during starting
( 451)
Bit Option Info
Bit 0 Control inverted Activation of inverted control
•"1" ≡ Inverted logic of trigger signal for holding brake control
switching element
Bit 1 nAct < nMin at CInh Brake response in case of pulse inhibit
•"1" ≡ With pulse inhibit, the actual speed value is monitored. The
holding brake is applied when the actual speed reaches the
"Application" threshold value.
• Note: This function is used to avoid the wear of the holding brake
of a drive with horizontal travel path when the controller is
inhibited and rotation occurs.
Bit 2 Inverted feedforward control Precontrol inversion
•"1" ≡ The direction of the precontrol value before setting the
release signal of the holding brake is inverted.
Bit 3 Horizontal/winding technology Direction of the axis
•"1" ≡ The direction of the axis is horizontal or rotary. The
gravitational acceleration does not cause any movement.
•"0" ≡ The direction of the axis is vertical. The gravitational
acceleration does not cause any movement.
Bit 4 Reserved
...
Bit 7
