8400 HighLine | Parameter setting & configuration
System bus "CAN on board"
Implemented CANopen objects
548 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
10.10 Implemented CANopen objects
Lenze devices can both be parameterised with Lenze codes and manufacturer-
independent "CANopen objects". A completely CANopen-compliant
communication can
only be achieved by using CANopen objects for parameter setting. The CANopen objects
described in this chapter are defined in the CAN specification DS301 V4.02.
Many CANopen objects can be mapped on Lenze codes. In the following table, the
corresponding Lenze codes are listed in the column "Relationship to Lenze codes".
Overview of CANopen indices and their relationship to Lenze codes
Note!
Some of the terms used here derive from the CANopen protocol.
CANopen object Relationship to Lenze
code
Index Subindex Name
I-1000
0 Device type -
I-1001
0 Error register -
I-1003
Predefined error field
0 Number of errors -
1 ... 10 Standard error field -
I-1005
0 COB-ID SYNC message C00367
C00368
I-1006 0 Communication cycle period C00369
I-1014 0COB-ID EMCY -
I-1016
Consumer heartbeat time
0 Highest subindex supported -
1 ... n Consumer heartbeat time
• "BaseLine C" version: n = 1
• "StateLine" version: n = 7
• "HighLine" version: n = 15
C00385/1...n
C00386/1...n
I-1017 0 Producer heartbeat time C00381
I-1018 Identity object
0 Highest subindex supported -
1Vendor ID -
2 Product code -
3 Revision number -
4 Serial number -
I-1200
SDO1 server parameter
0 Highest subindex supported -
1 COB-ID client −> server (rx) -
2COB-ID server −> client (tx) -
I-1201
SDO2 server parameter
0 Highest subindex supported -
1 COB-ID client −> server (rx) -
2COB-ID server −> client (tx) -
