8400 HighLine | Parameter setting & configuration
System bus "CAN on board"
Implemented CANopen objects
I-1005
This object can be used to activate the generation of sync telegrams and to write the
identifier value.
 This object relates to codes C00367
and C00368.
Creating sync telegrams
Sync telegrams are created by setting bit 30 (see below) to "1". The time between the sync
telegrams can be set using the object I-1006
.
Writing identifiers
To receive PDOs, the value 0x80 must be entered in the 11-bit identifier in the Lenze setting
(and according to CANopen specification) . This means that all
modules are by default set
to the same sync telegram.
 If sync telegrams are only to be received by certain
communication modules, their
identifiers can be entered with values up to and including 0x07FF.
 The identifier may only be changed when the communication module does not send
any sync telegram (bit 30 = "0").
 How to change the identifier:
– Deactivate identifier (set bit 30 to "0").
– Change identifier.
– Activate identifier (set bit 30 to "1").
[10-2] Data telegram assignment
Index:
I-1005
Name:
COB-ID SYNC message
Subindex Default setting Setting range (min. value | unit | max. value) Access Data type
0: COB-ID SYNC message 0x0000 0080
or
0x8000 0080
0 4294967295 rw U32
8th byte 7th byte 6th byte 5th byte
Data 4 Data 3 Data 2 Data 1
Bit 31 Bit 30 Bit 29 ... bit 11 Bit 10 ... Bit 0
X 0/1 Extended identifier* 11-bit identifier
* The extended identifier is not supported. Bit11...bit29 must be set to "0".
