Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010 L 651
8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00409
C00409
C00410
C00411
Parameter | Name:
C00409 | LP_CanIn mapping
Data type: UNSIGNED_16
Index: 24166
d
= 5E66
h
As of version 02.00.00
Mapping for port blocks LP_CanIn1...3
System bus "CAN on board": Port blocks
Setting range (min. value | unit | max. value)
0 65535
Subcodes Lenze setting Info
C00409/1 0 LP_CanIn1.wCtrl
C00409/2 0 LP_CanIn1.wIn2
C00409/3 0 LP_CanIn1.wIn3
C00409/4 0 LP_CanIn1.wIn4
C00409/5 0 LP_CanIn2.wCtrl
C00409/6 0 LP_CanIn2.wIn2
C00409/7 0 LP_CanIn2.wIn3
C00409/8 0 LP_CanIn2.wIn4
C00409/9 0 LP_CanIn3.wCtrl
C00409/10 0 LP_CanIn3.wIn2
C00409/11 0 LP_CanIn3.wIn3
C00409/12 0 LP_CanIn3.wIn4
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C00410 | L_SignalMonitor_a: Signal sources
Data type: UNSIGNED_16
Index: 24165
d
= 5E65
h
FB L_SignalMonitor_a: Selection of the signal sources
Selection list
See selection list - analog signals
Subcodes Lenze setting Info
C00410/1 0: Not connected Signal source for output nOut1_a
C00410/2 0: Not connected Signal source for output nOut2_a
C00410/3 0: Not connected Signal source for output nOut3_a
C00410/4 0: Not connected Signal source for output nOut4_a
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C00411 | L_SignalMonitor_b: Signal sources
Data type: UNSIGNED_16
Index: 24164
d
= 5E64
h
FB L_SignalMonitor_b: Selection of the signal sources
Selection list
See selection list - digital signals
Subcodes Lenze setting Info
C00411/1 0: Not connected Signal source for output bOut1
C00411/2 0: Not connected Signal source for output bOut2
C00411/3 0: Not connected Signal source for output bOut3
C00411/4 0: Not connected Signal source for output bOut4
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
