Lenze E84AVHC Series - C00024 | Comparison value N_Act; C00026 | AINx: Offset; C00027 | AINx: Gain; C00028 | AINx: Input voltage

Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010 L 595
8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00024
C00024
C00026
C00027
C00028
Parameter | Name:
C00024 | Comparison value N_Act
Data type: INTEGER_16
Index: 24551
d
= 5FE7
h
Threshold for the actual speed comparison
• This parameter serves to set a threshold that is compared with the actual speed value.
• When the value falls below this threshold, the bNactCompare output of the SB LS_DriveInterface
switches to
TRUE.
• Switching hysteresis = +1 %
Setting range (min. value | unit | max. value) Lenze setting
0.00 % 199.99 0.00 %
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00026 | AINx: Offset
Data type: INTEGER_16
Index: 24549
d
= 5FE5
h
Offset for analog inputs
Analog terminals
Setting range (min. value | unit | max. value)
-199.99 % 199.99
Subcodes Lenze setting Info
C00026/1 0.00 % AIN1: Offset
C00026/2 0.00 % AIN2: Offset
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00027 | AINx: Gain
Data type: INTEGER_32
Index: 24548
d
= 5FE4
h
Gain for analog inputs
Analog terminals
Setting range (min. value | unit | max. value)
-100.0000 100.0000
Subcodes Lenze setting Info
C00027/1 1.0000 AIN1: Gain
C00027/2 1.0000 AIN2: Gain
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10000
Parameter | Name:
C00028 | AINx: Input voltage
Data type: INTEGER_16
Index: 24547
d
= 5FE3
h
Display of the input voltage at the analog inputs
Analog terminals
Display range (min. value | unit | max. value)
-10.00 V 10.00
Subcodes Info
C00028/1 AIN1: Input voltage
C00028/2 AIN2: Input voltage
; Read access  Write access  CINH  PLC STOP ; No transfer  COM  MOT Scaling factor: 100
