8400 HighLine | Parameter setting & configuration
Function library
Function blocks | L_LimitPhi_3
980 L Firmware 05.00 - DMS 4.2 EN - 02/2010
14.1.82 L_LimitPhi_3
This FB limits an angle signal to a value range whose upper and lower value range can be
set via parameters.
Inputs
Outputs
Parameter
Tip!
Always set the lower limit lower than the upper limit, otherwise value "0" is
provided at the dnOut_p output.
Identifier
Data type
Information/possible settings
dnIn_p
INT
Input signal
Identifier
Data type
Value/meaning
dnOut_p
INT
Output signal
Parameter Possible settings Info
C00631/5
-2147483647 Incr. 2147483647 Lower limit
Lenze setting: -2147483647 incr.
C00631/6
-2147483647 Incr. 2147483647 Upper limit
Lenze setting: 2147483647 incr.
/B/LPLW3KLB
GQ,QBS GQ2XWBS
&
&
efesotomasyon.com - Lenze
