8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00412
652 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
C00412
C00413
C00420
Parameter | Name:
C00412 | L_SignalMonitor_b: Inversion
Data type: UNSIGNED_8
Index: 24163
d
= 5E63
h
FB L_SignalMonitor_b: Inversion of the binary outputs
Setting range (min. hex value | max. hex value) Lenze setting
0x00 0xFF 0x00 (decimal: 0)
Value is bit-coded: (; =bit set) Info
Bit 0 bOut1 inverted Bit set = inversion active
Bit 1 bOut2 inverted
Bit 2 bOut3 inverted
Bit 3 bOut4 inverted
Bit 4 Reserved
Bit 5 Reserved
Bit 6 Reserved
Bit 7 Reserved
; Read access ; Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C00413 | L_SignalMonitor_a: Offset/Gain
Data type: INTEGER_16
Index: 24162
d
= 5E62
h
FB L_SignalMonitor_a: Gain and offset of the analog signals
Setting range (min. value | unit | max. value)
-199.99 % 199.99
Subcodes Lenze setting Info
C00413/1 0.00 % Offset for output nOut1_a
C00413/2 100.00 % Gain for output nOut1_a
C00413/3 0.00 % Offset for output nOut2_a
C00413/4 100.00 % Gain for output nOut2_a
C00413/5 0.00 % Offset for output nOut3_a
C00413/6 100.00 % Gain for output nOut3_a
C00413/7 0.00 % Offset for output nOut4_a
C00413/8 100.00 % Gain for output nOut4_a
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C00420 | Encoder number of increments
Data type: UNSIGNED_16
Index: 24155
d
= 5E5B
h
Indication of the encoder constant
Encoder/feedback system
Setting range (min. value | unit | max. value)
1 Incr./rev. 32768
Subcodes Lenze setting Info
C00420/1 128 incr./rev. Encoder increments at FreqIn12
C00420/2 128 incr./rev. Encoder increments at FreqIn67
; Read access ; Write access ; CINH PLC STOP No transfer COM MOT Scaling factor: 1
