8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00595
674 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
C00595
C00597
Parameter | Name:
C00595 | MCK: Resp. to MCK error
Data type: UNSIGNED_8
Index: 23980
d
= 5DAC
h
Configuration of monitoring of the Motion Control Kernel
Basic drive functions
Selection list
0 No Reaction
1Fault
3 TroubleQuickStop
4 WarningLocked
5 Warning
6 Information
Subcodes Lenze setting Info
C00595/1 3: TroubleQuickStop Response if the input bLimitSwitchPos for travel range
monitoring is set to FALSE (fail-safe) by the positive
hardware limit switch .
C00595/2 3: TroubleQuickStop Response if the input bLimitSwitchNeg for travel range
monitoring is set to FALSE (fail-safe) by the negative
hardware limit switch .
C00595/3 3: TroubleQuickStop Response for detection that the position is beyond the
positive software limit position (C01229/1
).
C00595/4 3: TroubleQuickStop Response for detection that the position is beyond the
negative software limit position (C01229/2
).
C00595/5 5: Warning Response if following error limit 1 is exceeded (C01215/
1)
C00595/6 5: Warning Response if following error limit 2 is exceeded (C01215/
2)
C00595/7 3: TroubleQuickStop Response if the maximum travel distance (display in
C01213/1
) is exceeded
C00595/8 4: WarningLocked Response to start procedures with reference condition
when the reference is not set
C00595/9 4: WarningLocked Response to a non-supported positioning mode
C00595/10 4: WarningLocked Response to implausible profile set data
C00595/11 5: Warning Response to the selection of an invalid operating mode
of the MCK
C00595/12 4: WarningLocked Response to indicating an invalid profile data set
C00595/13 5: Warning Response to an error of the FB L_MckCtrlInterface_1
C00595/14 4: WarningLocked Response to a profile start with a target position outside
the software limit positions (C01229/1
and C01229/2).
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C00597 | Resp. to motor phase failure
Data type: UNSIGNED_8
Index: 23978
d
= 5DAA
h
Response to motor phase failure
• If a phase current does not exceed the threshold set in C00599
over a period, the response set here is effected.
Selection list (Lenze setting printed in bold)
0No Reaction
1Fault
5 Warning
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
