Lenze E84AVHC Series User Manual

Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010 L 629
8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00223
C00223
C00224
C00225
C00226
C00227
C00228
Parameter | Name:
C00223 | L_PCTRL_1: Tn
Data type: UNSIGNED_16
Index: 24352
d
= 5F20
h
FB L_PCTRL_1: Reset time Tn for the PID process controller
Setting range (min. value | unit | max. value) Lenze setting
20 ms 6000 400 ms
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00224 | L_PCTRL_1: Kd
Data type: UNSIGNED_16
Index: 24351
d
= 5F1F
h
FB L_PCTRL_1: Derivative-action coefficient Kd for the PID process controller
Setting range (min. value | unit | max. value) Lenze setting
0.0 5.0 0.0
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10
Parameter | Name:
C00225 | L_PCTRL_1: MaxLimit
Data type: INTEGER_16
Index: 24350
d
= 5F1E
h
FB L_PCTRL_1: Maximum output value of the PID process controller
Setting range (min. value | unit | max. value) Lenze setting
-199.99 % 199.99 199.99 %
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00226 | L_PCTRL_1: MinLimit
Data type: INTEGER_16
Index: 24349
d
= 5F1D
h
FB L_PCTRL_1: Minimum output value of the PID process controller
Setting range (min. value | unit | max. value) Lenze setting
-199.99 % 199.99 -199.99 %
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00227 | L_PCTRL_1: Acceleration time
Data type: UNSIGNED_32
Index: 24348
d
= 5F1C
h
FB L_PCTRL_1: Acceleration time for the output value of the PID process controller
Setting range (min. value | unit | max. value) Lenze setting
0.000 s 999.999 0.010 s
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1000
Parameter | Name:
C00228 | L_PCTRL_1: Deceleration time
Data type: UNSIGNED_32
Index: 24347
d
= 5F1B
h
FB L_PCTRL_1: Deceleration time for the output value of the PID process controller
Setting range (min. value | unit | max. value) Lenze setting
0.000 s 999.999 0.010 s
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1000
