8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00968
C00968
C00971
C00972
Parameter | Name:
C00968 | VFC: Voltage at curve interpolation point n
Data type: UNSIGNED_16
Index: 23607
d
= 5C37
h
As of version 04.00.00
Selection of the curve interpolation points (voltage values) for the VFCplus operating mode with user-definable V/
f characteristic (C00006
= "10")
Setting range (min. value | unit | max. value)
0.00 V 600.00
Subcodes Lenze setting Info
C00968/1 400.00 V VFC: Voltage at curve interpolation point 1
C00968/2 320.00 V VFC: Voltage at curve interpolation point 2
C00968/3 240.00 V VFC: Voltage at curve interpolation point 3
C00968/4 160.00 V VFC: Voltage at curve interpolation point 4
C00968/5 80.00 V VFC: Voltage at curve interpolation point 5
C00968/6 0.00 V VFC:Voltage at curve interpolation point 6
C00968/7 80.00 V VFC:Voltage at curve interpolation point 7
C00968/8 160.00 V VFC:Voltage at curve interpolation point 8
C00968/9 240.00 V VFC:Voltage at curve interpolation point 9
C00968/10 320.00 V VFC:Voltage at curve interpolation point 10
C00968/11 400.00 V VFC: Voltage at curve interpolation point 11
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C00971 | VFC: Limitation V/f +encoder
Data type: UNSIGNED_16
Index: 23604
d
= 5C34
h
Limitation of the output frequency of the slip regulator and limitation of the injected stator frequency for
VFCplus+encoder mode
Setting range (min. value | unit | max. value)
0.00 Hz 100.00
Subcodes Lenze setting Info
C00971/1 10.00 Hz Maximum output/ correcting variable of the slip
regulator
• The slip regulator output is limited to the value in
motor mode and in generator mode set here.
• It is recommended to select 1 to 3-times the slip
frequency of the motor as limit value.
C00968/2 100.00 Hz Maximum frequency deviation between the rotational
frequency (speed) measured mechanically by the
encoder and the injected stator frequency.
• Through a limitation, you can e.g. avoid an
overcurrent interruption when traversing to a fixed
limit stop.
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C00972 | VFC: Vp V/f +encoder
Data type: UNSIGNED_16
Index: 23603
d
= 5C33
h
Proportional gain of the slip regulator for VFCplus+encoder mode
• Select the gain depending on the drive system and the encoder resolution (range from 0.005 ... 5).
• High gain values require a high PPR count.
Setting range (min. value | unit | max. value) Lenze setting
0.000 Hz/Hz 64.000 0.100 Hz/Hz
; Read access ; Write access CINH PLC STOP No transfer COM ; MOT Scaling factor: 1000
